947 is suitable for both on-wall and in-wall installations. The small depth makes it easy to use together with projector screens or in places where the use of big floor speakers is limited.
A high sensitivity, power of a professional speaker and the sound of a High-End system makes these loudspeakers unique.
For the best reproduction of low frequencies a sealed enclosure with thick walls is used. This gives very good dynamics and a well-controlled tight bass for the system, but also eases the use of an additional subwoofer. The symmetrical construction makes the system universal – it can be used as a right, left or centre loudspeaker. This construction also minimises the side reflections from walls and the floor, which is very important in big rooms.
The system has a correction switch for the sound. The suggested positions are ‘O’ for on-wall and ‘I’ for in-wall. The system is equipped with decorative grill. If needed, a special fastening system is offered for an on-wall installation.
Nominal impedance - 4 Ω
Max. long-term power - 250 W
Max. short-term power - 400 W
Frequency range (±2 dB) - 72–20000 Hz
Lf corner (−6 dB) - 54 Hz
Crossover frequency - 500/2500 Hz
Sensitivity (2.83 V/1 m) - 92 dB
Speaker drivers:
1) 2 × 8" paper cone woofer. Designed & manufactured by Audes;
2) 2 × 5" paper cone mid-woofer;
3) 1" fabric dome tweeter.
Dimensions (mm) - 1444 H × 356 W × 102 D
Grill On-Wall - 1444 H × 356 W × 12 D
Grill In-Wall - 1520 H × 432 W × 12 D
Dimensions (inches) - 56⅞" H × 14" W × 4" D
Grill On-Wall - 56⅞" H × 14" W × ½" D
Grill In-Wall - 59⅞" H × 17" W × ½" D
Weight - 22 kg/49 lbs
The standard finish for 947 is black paint.
