CLASSIC 102   Power Amplifier

One of the main features of this amplifier is its ability to amplify the audio signal without distortion and with a high dynamic range. The sound is reproduced with the highest possible fidelity, without background noise, alterations in the frequency response and the typical distortion that limits the dynamic sense of the music. is a 100 watt per channel class AB amplifier. It is compact, powerful and robust but at the same time capable of capturing the smallest nuances of even the most complex musical pieces. Notable features of the amplifier are the independent and decoupled left and right power stages. The layout is essentially dual mono. Other design features are the choice of high quality capacitors that provide plenty of reserve energy for extremely dynamic audio passages. The input connections are represented by balanced XLR or unbalanced RCA connectors. high quality in an intuitive and fast way.

In this new stereo amplifier we have substantially increased the power of the power supply stage and developed the entire project with a dual mono philosophy. Each channel has separate and excellently filtered and stabilized power supplies, as well as the entire ground planes. This allows for extremely effective channel separation that translates into a very natural sound, with incredible and realistic focus and stage reconstruction. Each instrument remains well focused in space and the powerful power supply section favors unprecedented dynamics.

The wiring reduced to a minimum, the conversion of the line inputs to balanced guarantee absolute and unchangeable performance over time.

The entire project is completed by a connection park that allows for extreme versatility, such as the link outputs for connecting one or more amplifiers in cascade for multi-way audio systems and the trigger for automatically switching on all the units .

Balanced circuitry. It's our philosophy and we are proud to develop it to the best of our ability and always have.

There are many conflicting opinions on this configuration. Some say it is useless in a domestic environment, others say it degrades and dirties the sound, and others say it only serves to determine a higher cost of the equipment for purely commercial purposes.

In part, this may only be true if this aspect of the project is neglected or poorly designed.

Recent field tests have also demonstrated that if the overall design is executed according to the rules of the art, the final result can be considered the maximum in terms of musicality, transparency and dynamics.

Technical SpecificationsDual mono power amplifier

• RMS power per channel, both channels driven @1Khz -

100W @ 8ohm

180W @ 4ohm

290W @ 2ohms

• EIA power per channel, both channels driven / 20hz- 20Khz. -

190W @ 8ohm

300W @ 4 ohms

450W @ 2 ohms

• THD + N – A-weighted - 0.003% at full power into 8 ohms

• Input -

1 balanced input via XLR

1 line input

• exits -

link via XLR

1 pair of 6mm Binding posts

• Input impedance: -

47 Kohm via XLR, 22 Kohm via RCA

• Slew/rate - 35V/uS

• Frequency response - From 20Hz to 40Khz +/- 0.2db

• Channel separation - > 81 db• A-weighted SNR >102 db

• Dimensions - 38 ––x 42 x 11 cm. ( D x W x H )

• Weight - 15 kg

USER MANUAL

SAFETY INFORMATION
This device is subject to mains voltage. To avoid the risk of electric shock,
do not open the cover, expose it to moisture or rain, or attempt to make
modifications or repairs. Seek assistance only from certified and
qualified personnel.
Safety Information:
1. To achieve optimal performance, carefully read this manual. Keep it in a
safe place for future reference.
2. Install the unit in a cool, dry, and clean location away from windows, heat
sources, intense vibrations, dust, moisture, cold, and buzzing sources
(transformers, motors, etc.). To prevent the risk of fire or electric shock,
do not expose the unit to water and moisture.
3. Never open the equipment. If something enters inside, contact your
dealer.
4. Do not use switches and other controls with force. When moving the unit,
first disconnect the power cord and cables connected to other devices.
Never pull the wires themselves. NOTE: The cover openings provide
adequate ventilation for the unit. If these openings are obstructed, the
temperature inside rises rapidly. Therefore, install the unit in a wellventilated location, avoiding placing various objects in front of these
openings to prevent damage. Leave at least 5 cm of space behind, 5
cm on both sides, and 5 cm above the top panel of the machine to avoid
sudden overheating.
5. The voltage used must be as specified. Using this product with a
current whose voltage is higher than specified is dangerous and can cause
damage. EAM LAB is not responsible for any damage due to improper use
of the equipment.
