CLASSIC 202i integrated amplifier
CLASSIC 202I was conceived, designed and implemented to further improve the sound reproduction of our previous MUSICA series integrated amplifiers while also incorporating the latest in connections for streaming digital content. We are not afraid to say that we have entered a new era of low-noise, highharmonic-contrast circuitry. this was possible thanks to a new circuit design, a modern volume control system, latest generation components and a series of advanced features that guarantee you crystal clear
and precise sound.
One of the main features of CLASSIC 202i is its ability to amplify the audio signal without distortion and with a high dynamic range. The sound is reproduced with the highest possible fidelity, without background noise, alterations in the frequency response and, thanks to its powerful power supply, the typical distortion that limits the dynamic sense of the music.
The 102i also features a host of audio inputs and outputs, making it compatible with a wide range of devices. An exceptional MM phono input, two balanced inputs and 3 line inputs make it possible to use this modern electronics with any source, from CD players to turntables. The DAC with Hyperstream technology
implemented on the SABRE ESS 9038 q2m further expands the possibilities of connections for digital and streaming usability with an exciting level of unparalleled playback.
Finally, we also designed it to be easy to use and set up. Thanks to its simple and intuitive interface, you can set it up in just a few minutes and start enjoying high quality sound in modo intuitivo ,semplice e veloce.
Balanced and dual mono circuitry
In the new 202i we have substantially increased the power of the power supply stage and we have developed the entire project with dual mono architecture. Each channel has separate and excellently filtered and stabilized power supplies, as do the entire ground planes. This allows for extremely effective channel separation which
translates into a very natural sound, with incredible and realistic focus and stage reconstruction. Each instrument remains well focused in space and the powerful power section promotes unprecedented dynamics.
The wiring reduced to a minimum, the conversion of the line inputs to balanced and the possibility of integrating the machine with audio/video systems guarantee absolute and immutable performance over time. The entire project is completed by a high-performance RIAA PHONO section for lovers of vinyl records and the possibility of using the PRE-OUT / AMP-IN outputs selectable by remote control for unprecedented versatility.
The balanced circuitry. It is our philosophy and we are proud to develop it to the best of our ability and always.
There are many conflicting opinions on this configuration. There are those who say that it is useless in the domestic environment, those who say that it degrades and dirty the sound, others that it only serves to determine a higher cost of the equipment for purely commercial purposes. In part, all of this could only be true if this aspect of the project is neglected or poorly designed. Recent technical field tests have also demonstrated that if the overall project is executed to perfection, the final result can be considered the maximum in terms of musicality, transparency and dynamics.
In the CLASSIC 202i nothing has been left to chance, starting from a dual mono power supply and circuitry up to the actual heart where each amplification section is double. including the innovative volume control that uses two separate stages for each channel on an array of digitally controlled MOSFETs. Furthermore, thanks to its native balanced nature, even single ended line inputs are entirely converted to balanced, including the PHONO RIAA stage. Simply put, you won't hear a more dynamic and transparent preamp than
this one
The volume control section, a stage not to be underestimated.
The most delicate, fundamental part and to be treated with extreme care, because it is also this stage that overall determines the general performance of reproduction Unlike many manufacturers who use classic motorized potentiometers, we have developed a completely different stage which guarantees the project a set of very important performance advantages. We have implemented gain control via an array of armored Mos-fets in a special IC which are controlled digitally. As a first factor, we have forever eliminated the wear of the carbon layer typical of traditional potentiometers and this forever eliminates the onset of the annoying Hum & Noise and Pop & Click that are inevitable with wear over time.
Another advantage that is often overlooked is the linearity of the response which is modified as the volume increases or decreases with the use of carbon layer potentiometers or even the more sophisticated resistor array potentiometers. This happens when a resistance is found in the signal passing through the potentiometer which also modifies its impedance factor and which causes this artefact.
DAC section
202i is equipped with a latest generation DAC stage which further expands the inputs for new digital technologies. 3 additional inputs between USB, COAX and OPTICAL make the amplifier extremely versatile with a wide choice of connection options to best enjoy music from your favorite source. Whether it is usable from streaming, from a CD player or from the television, with this section you will get the best in terms of reproduction and musicality.
The DAC reads files with conversion up to 384 Khz in PCM and DSD 256 in Dop or DSD 512 natively. The DAC card can also be replaced and updated at any time to always have the latest innovations in the digital audio field at hand.
PRACTICAL AND FUNCTIONAL CONNECTIONS
The multiple connections make it versatile in any system as a pure integrated amplifier or even as a preamplifier / power amplifier by integrating it into already existing complex systems. To leave nothing to chance, the specific PRE-OUT and AMP-IN outputs can also be managed in a balanced connection and can be enabled from the practical touch screen display or remote control.
Native balanced dual mono integrated amplifier
·RMS power per channel, both channels driven @1Khz -
200W @ 8 ohms
330W @ 4ohm
·EIA power per channel, both channels driven / 20hz- 20Khz. -
280W @ 8 ohms
420W @ 4ohm
·THD + N – A-weighted - 0.003% at full power into 8 ohms
·Input -
2 balanced input viaXLR
3 line inputs
1 RIAA MM phono input
1 selectable AMP-IN input
·exits -
1 pair of RCAPRE-OUT
1 pair of 6mm Binding posts
·Input impedance: - 47 Kohm via XLR, 22 Kohm via RCA
·Slew/rate - 35V/uS
·Frequency response - From 20Hz to 90Khz+/- 0.2db
·Phono input - MM – 47Khom – 41db gain
·DAC section - USB – 784 Khz pcm – DSD256 in Dop mode / native DSD 512COAX
optical
·Channel separation - > 80 db·A
weighted SNR - >104 db
·Dimensions - 46 ––x 42 x 13 cm.( D x W x H )
·Weight - 20 kg
USER MANUAL
This device is subject to mains voltage. To avoid the risk of electric shock,
do not open the cover, expose it to moisture or rain, or attempt to make
modifications or repairs. Seek assistance only from certified and
qualified personnel.
Safety Information:
1. To achieve optimal performance, carefully read this manual. Keep it in a
safe place for future reference.
2. Install the unit in a cool, dry, and clean location away from windows, heat
sources, intense vibrations, dust, moisture, cold, and buzzing sources
(transformers, motors, etc.). To prevent the risk of fire or electric shock,
do not expose the unit to water and moisture.
3. Never open the equipment. If something enters inside, contact your
dealer.
4. Do not use switches and other controls with force. When moving the unit,
first disconnect the power cord and cables connected to other devices.
Never pull the wires themselves. NOTE: The cover openings provide
adequate ventilation for the unit. If these openings are obstructed, the
temperature inside rises rapidly. Therefore, install the unit in a wellventilated location, avoiding placing various objects in front of these
openings to prevent damage. Leave at least 5 cm of space behind, 5
cm on both sides, and 5 cm above the top panel of the machine to avoid
sudden overheating.
5. The voltage used must be as specified. Using this product with a
current whose voltage is higher than specified is dangerous and can cause
damage. EAM LAB is not responsible for any damage due to improper use
of the equipment.
REMOTE CONTROL
FUNCTIONS
PWR power on/off
DSP not used
V+ / V- encrease/decrease
Volume
MUTE mute outputs
CH+ / CH- select sources
SET configurations menu
BATTERY REPLACEMENT
Only use CR 2032 model batteries.
To replace, remove the 4 screws on the bottom side of the remote
control. The battery is on the bottom of the circuit board. Ensure
correct polarity.
The remote control transmits a directional infrared beam. During
operation, ensure to point the remote towards the sensor.
If the sensor is covered and obstructed by large objects, it will not
receive the signal. The sensor may not be able to properly receive
signals when exposed to direct sunlight or strong artificial light.
! If the remote control only works when close to the unit, the
batteries are running low. Replace them with new batteries.
