CLASSIC 302 power amplifier
We have entered a new era of high-quality music playback components. CLASSIC 302 has been designed with care and attention to the smallest details, both internally and externally.
A new circuit design, latest generation devices, a new design for power transformers. All mixed with our twenty years of experience in the sector to guarantee sound reproduction with absolute fidelity.
The heart of our performance: the power stage
the true heart of every amplifier, especially for our amplifiers, is for us a given of extreme care and detail of fundamental importance, resources and commitment.
CLASSIC 302 is equipped with two transformers with separate windings and wound on a single core for a total power of 1,200 Va which power the rectifier circuits mounted on a single PCB without loose wiring such as to allow a connection without contact resistors. This design shortens the electrical path from the transformer to the final output stages, reducing overall impedance and allowing the circuit to respond faster while better controlling the speakers and more accurately.
The power transformer
This is where the greatest resources are used to guarantee maximum sound performance. Undersized or poorly designed transformers contribute to a degradation of the sound message through mechanical vibrations and a dispersed magnetic flux entering the delicate circuits.
Even high inductions, often used to save on the number and cost of windings, contribute to the decline in performance, often resulting in premature saturation of the core with the consequent limit of the maximum current that can be delivered.
The technology in our transformers
DIMENSIONS and WEIGHT: it is an almost certain data to ensure good performance, however these two measurements if considered as an end in themselves do not guarantee the final result. It is a set of further additional factors that determine the difference between a good transformer and an excellent transformer.
We cannot tell you point by point how we build our transformers being subject to factory veto but we can describe the major requirements to understand the efforts implemented in 20 years of research, study and evolution of materials that we use on a large scale. Such as an extremely low induction, toroidal cores made of iron and magnesium powder, innovative coil winding and interlacing technique and last but not least, a copper magnetic shielding throughout the body.
You won't hear a more stable and silent transformer than ours!
Balanced connections. Why prefer them
There are many conflicting opinions on this connection. There are those who say that they are useless in t he domestic environment, those who say that they degrade and dirty the sound, others that they only serve to determine a higher cost of the equipment for purely commercial purposes. n part, all of this could only be true if this aspect of the project is neglected or poorly designed. ecent technical field tests have also demonstrated that if the overall project is executed to perfection, the final result can be considered the maximum in terms of musicality, transparency and dynamics.
Think about it: with a signal that travels in counter-phase on two conductors and a screen braid that only a cts as a screen (in single ended the screen also carries the signal) the swing voltage rate is increased. The signal is transferred without losses and interference to the receiving component which "decomposes" it, determines the wrong values and eliminates them from the sound message.
Balanced input stage, our philosophy
The most delicate, fundamental part and to be treated with extreme care, because it is also this stage that overall determines the general performance of reproduction this delicate task is entrusted to our proprietary HDCA modules now in their third version. Today even more refined, clear and transparent. we assemble them with components selected for their linearity and bandwidth characteristics. The circuit operates in an open loop and the feedback is so low as to become practically negligible.
The circuit operates in pure class A and does not use decoupling capacitors across the various signal processing stages.
What does this mean when translated into sound?
Greater transparency and therefore detail, better sharpness, greater and more contrasting dynamics, an increased infra-instrumental black that sculpts and contours every single voice and instrument of the sound message.
The power Stage
revolves around a circuit design in helmet configuration. This tested configuration of ours allows a wide and extended bandwidth and the driving of the power amplifiers takes place via a Darlington type configuration. 8 pairs per channel of latest generation bipolar transistors ensure reliability and stability in any condition of use, load or current request.
A new integration of the circuits with SMD components allows shorter signal paths, greater noise rejection and a notable decrease in "microphonics" due to vibrations
The power transformer, in addition to being shielded, is mounted under an iron cover which further increases its rejection of disturbances. The entire filter bank and the rectifier diodes are instead mounted on a PCB with 70 micron copper without air wiring.
This decreases the contact resistance providing a higher current input and with greater transfer speed increasing the damping factor and control over the speakers
Technical SpecificationsDual mono power amplifier
• RMS power per channel, both channels driven @1Khz
330W @ 8 ohms
600W @ 4 ohms
1000W @ 2ohms
• EIA power per channel, both channels driven / 20hz- 20Khz.
520W @ 8 ohms
900W @ 4 ohms
1400W @ 2 ohms
• THD + N – A-weighted - 0.003% at full power into 8 ohms
• input sensitivity - 2.4 Vrms for full power @ 8 ohms
• exits - 1 pair of 6mm Binding posts
• Input impedance: - 47 Kohm via XLR, 22 Kohm via RCA
• Slew/rate - 35V/uS
• Frequency response - From 20Hz to 80Khz +/- 2db
• Channel separation - > 80 db• A-weighted SNR >110db
• Dimensions - 43x 42 x 21 cm. (D x W x H)
• Weight - 38 kg
USER MANUAL
CLASSIC 302 power amplifier
We have entered a new era of high-quality music playback components. CLASSIC 302 has been designed
with care and attention to the smallest details, both internally and externally.
A new circuit design, latest generation devices, a new design for power transformers. All mixed with our
twenty years of experience in the sector to guarantee sound reproduction with absolute fidelity.
The new transformers guarantee stability and precision of the sound message even at low impedances and
high listening pressures. The proven dual mono implementation provides greater signal stability and better
channel separation which translates into a wide, deep soundstage with well-positioned instruments within
the sound message, making the speakers literally disappear.
This amplifier is able to drive a wide range of speakers, thanks to its power reserve and inexhaustible
current. Furthermore, its elegant and modern design fits perfectly into any environment, making it a perfect
complement to your audio system.
The heart of our performance: the power stage
the true heart of every amplifier, especially for our amplifiers, is for us a given of extreme care and detail of
fundamental importance, resources and commitment.
CLASSIC 202 is equipped with two transformers with separate windings and wound on a single core for a total
power of 1,200 Va which power the rectifier circuits mounted on a single PCB without loose wiring such as to allow
a connection without contact resistors.
This design shortens the electrical path from the transformer to the final output stages, reducing overall impedance
and allowing the circuit to respond faster while better controlling the speakers and more accurately.
The power transformer :
this is where the greatest resources
are used to guarantee maximum
sound performance. Undersized or
poorly designed transformers
contribute to a degradation of the
sound message through mechanical
vibrations and a dispersed magnetic
flux entering the delicate circuits.
Even high inductions, often used to
save on the number and cost of
windings, contribute to the decline in
performance, often resulting in
premature saturation of the core with
the consequent limit of the maximum
current that can be delivered
The technology in our transformers
DIMENSIONS and WEIGHT:
it is an almost certain data to ensure good performance, however these two
measurements if considered as an end in themselves do not guarantee the final result. It is a set of further additional factors that determine the difference between a good transformer and an excellent transformer.
We cannot tell you point by point how we build our transformers being subject to factory veto but we can describe the major requirements to understand the efforts implemented in 20 years of research, study and evolution of materials that we use on a large scale.
Such as an extremely low induction, toroidal cores made of iron and magnesium powder, innovative coil winding and interlacing technique and last but not least, a copper magnetic shielding throughout the body.
You won't hear a more stable and silent transformer than ours!
Balanced connections. Why prefer them
There are many conflicting opinions on this connection. There are those who say that they are useless in
the domestic environment, those who say that they degrade and dirty the sound, others that they only
serve to determine a higher cost of the equipment for purely commercial purposes.
In part, all of this could only be true if this aspect of the project is neglected or poorly designed.
Recent technical field tests have also demonstrated that if the overall project is executed to perfection, the
final result can be considered the maximum in terms of musicality, transparency and dynamics.
Think about it: with a signal that travels in counter-phase on two conductors and a screen braid that only
acts as a screen (in single ended the screen also carries the signal) the swing voltage rate is increased. The signal is transferred without losses and interference to the receiving component which "decomposes" it, determines the wrong values and eliminates them from the sound message.
What does this mean when translated into sound?
Greater transparency and therefore detail, better sharpness, greater and more contrasting dynamics, an increased infra-instrumental black that sculpts and contours every single voice and instrument of the sound message.
The power Stage
revolves around a circuit design in helmet configuration. This tested configuration of ours allows a wide and
extended bandwidth and the driving of the power amplifiers takes place via a Darlington type configuration.
8 pairs per channel of latest generation bipolar transistors ensure reliability and stability in any condition of
use, load or current request.
A new integration of the circuits with SMD components allows shorter signal paths, greater noise rejection
and a notable decrease in "microphonics" due to vibrations
