CEC DA 5 - D/A Converter USB Sound System

 32bit/384 kHz PCM - DSD 256/11.2 MHz - ESS Hyperstream DAC chip

“You should make a note of the name DA 5. The new D/A converter of the well known Japanese manufacturer CEC makes an excellent all-round impression. It scores with inner values, such as the built-in exception-DAC chip ES9018K2M and can function with its innovative volume control and the headphone amplifier as the heart of a high quality audio system.

The new CEC DA 5 has the stuff to be the heart of a modern audio system. You can not only enjoy the music from the CD drive through it, but also from a Music Streamer or a PC - and at the highest resolution level DSD 256/11.2MHz. But that‘s not all. The CEC DA 5 has a newly developed digital volume control, which can adjust the analogue volume level in extremely fine increments from -99 dB to 0 dB. This is not only useful because the D/A converter acts as a headphone amplifier, but also because it can be used just as well as a preamplifier. The CEC DA 5 is easily connected to a power amp or powered speakers - and the high quality audio system is ready to go! The new CEC DA 5 is simply a very strong statement in digital playback.“ (Hifi Stars - 2016)

The conversion from digital to analogue signal is performed by the ESS Hyper stream DAC chip ES9018K2M compatible with 32bit - 384kHz PCM and 11.2MHz - DSD 256. Exceptional channel separation and wide dynamic range result in reproducing music with unbelievable breath and depth of sound stage. CEC DA 5 offers two different digital filters. “FLAT”, a standard filter with super linear frequency response to 20kHz, and “PULSE”, a ringing-free pulse-optimized filter with a softer roll-off below 20kHz.

Digital Inputs: SPDIF: Balanced type AES/EBU, Coaxial and Toslink are compatible with 24bit/192kHz.

USB: PCM32bit/384kHz and Native reproduction of DSD256/11.2MHz are available.

Both conventional type RCA and balanced type XLR connections are available. We recommend the balanced connection to make CEC DA 5 balanced circuit superiority perform at its finest.  incorporating it’s high performance headphones amplifier circuit the CEC DA 5 can be used even as an audiophile headphone amplifier. Digital volume control can adjust the analog output level at the digital domain. Adjustments from -99dB up to 0dB without deteriorating sound quality are possible. You may even connect directly to a power amplifier and/or active loudspeakers, and adjustments are done via remote control. Once output level has been set it is memorized even after power is off. LED monitor indicates the input status, input sampling frequency and filter condition. You may select the light condition out of three steps of brightness according to your listening condition.
