D/A CONVERTER CHIP - 2x AKM AK4493

FREQUENCY RESPONSE - 20Hz-20kHz +/-0.1dB

THD (Total Harmonic Distortion) - 0.001% max

SIGNAL TO NOISE RATIO - 125dB

DYNAMIC RANGE - 120dB

PREAMP STAGE VOLUME CONTROL - Available only on DS-1000 EVO LINE

NETWORK CONNECTIVITY - LAN/WLAN (WiFi) 802.11a/b/g/n/ac

Dual Band (10/433Mbps)

Bluetooth: High Definition 5.0 (44/16)

HIGH QUALITY STREAMING - Roon Ready, Airplay, MQA, Qobuz, Deezer, Spotify Connect, Tidal, Tidal Connect, vTuner

SUPPORTED AUDIO FORMATS - PCM up to 32bit/384kHzDSD up to DSD256 (DSF, DFF)AIFF (.aif, .aiff, .aifc)ALACWAV (.wav) packed/unpackedFLACMP3Apple LosslessOGGMonkey’s

SUPPORTED MEDIA SERVERS - UPnP*DLNARoon*UPnP server must support DSD streaming to play DSD files

DIGITAL INPUTS - 1x RCA coaxial PCM up to 24bit/192kHz

1x AES/EBU balanced PCM up to 24bit/192kHz

2x TOS-Link PCM up to 24bit/192kHz

1x USB-B asynchronous up to DSD512 and PCM up to 32bit/384kHz

1x USB-A port DSD256 and PCM up to 32bit/384kHz, formatted in FAT32/NTFS (32Gb max for pen drives)

ANALOGUE INPUTS - DS-1000 EVO LINE ONLY

1x RCA unbalanced

1x XLR balanced

AUDIO OUTPUTS DAC - 1x RCA 2Vrms1x XLR 2Vrms

AUDIO OUTPUTS PREAMP - 1x RCA unbalanced

1x XLR balanced1x headphone 6,3mm jack on front panel

OUTPUT IMPEDANCE - RCA 50ΩXLR 100Ω

POWER SUPPLY - 100-240V / 50-60Hz

POWER CONSUMPTION - 30W

FUSE - 2A T

DIMENSIONS - 430mm W | 135mm H | 375mm D

WEIGHT - Kg. 10 – net

Kg. 15 – boxed

BLACK
Black anodised aluminium with a traditional brushed finish

SILVER
Silver anodised aluminium with a traditional brushed finish

GOLD
Gold anodised aluminium with a traditional brushed finish

DS-1000 EVO

DAC: Dual/Mono AKM AK4493
Resolution: up to DSD512 and PCM 32bit/384kHz
Digital inputs: Ethernet, USB-A, USB-B, AES/EBU, COAX, TOS

DS-1000 EVO LINE

DAC: Dual/Mono AKM AK4493
Resolution: up to DSD512 and PCM 32bit/384kHz
Digital inputs: Ethernet, USB-A, USB-B, AES/EBU, COAX, TOS
Analogue inputs: XLR balanced, RCA unbalanced
Preamplifier: Class A preamp stage with discrete components

REMOTE CONTROL - Multifunctional remote control included

EXTERNAL POWER SUPPLY - PSU-1250 or PSU-1000 External Inductive Power Supply
