TUBE-1006 - Totem-Pole Output Stage design
MAX INPUT (THD < 1%) - RCA 6VrmsXLR 12Vrms
MAX OUTPUT (THD < 1%) - RCA 8VrmsXLR 16Vrms
OUTPUT IMPEDANCE - <600Ω
GAIN - 2dB
RECOMMENDED LOAD - >10kΩ
TUBES - TUBE-1006 – 6 valves 6n1p
TUBE-1012 – 12 valves 6n1p
THD+N - 0.0028% @ 1kHz – 1.736V
S/N - >100dB @ 1kHz – 1.736V
INPUTS TUBE
1x XLR Line In
1x RCA Line In
1x Tube In (5-pole XLR for Gold Note sources only)
POWER CONSUMPTION - TUBE-1012 – 80W
TUBE-1012 – 80W
POWER SUPPLY - 100-120V or 220-240V, 50/60Hz
Super Linear Vacuum Tube Regulator with 4 Inductive Choke filters
FUSE (220/240V) - 2A F
FUSE (100/120V) - 3,15A F
DIMENSIONS - 430mm W | 135mm H | 370mm D
WEIGHT - TUBE-1006 – Kg. 13,3 net – Kg. 19 boxed
BLACK
Black anodised aluminium with a traditional brushed finish
SILVER
Silver anodised aluminium with a traditional brushed finish
GOLD
Gold anodised aluminium with a traditional brushed finish

TUBE-1012
12 valves
Power consumption 80W
3x Gold Note custom transformer
TUBE-1006
6 valves
Power consumption 50W
2x Gold Note custom transformer
